End Drain
No Remote Parts - All Built-in
Reinforced Acrylic Construction

Comfort & Operation

• Super quiet 1.25hp water pump
• Direction control on 4 back and 2 foot jets with speed and direction control on 4 side jets
• In-line water heater
• Super quiet 0.5hp air variable speed warmed air blower
• 12 air jets with backflow prevention on the tub floor
• Waterproof remote control operation
• All jets are supplied in white to match tub

Hygiene & Maintenance

• Automatic purge cycle

Installation & Requirements

• Victoriana faucet in choice of finish (can be optioned out)
• Flexible hot and cold water supply lines to deck mounted faucet
• Integrated drain and overflow in choice of finish
• This tub requires two standard 15amp-110volt GFCI connection

Safety & Compliance

• Meets or exceeds ASME A112.19.7/CSA B45.10
• All electrical components UL listed
• MA Code accepted

Additional Features

• Ozone sanitizing
• Chromotherapy underwater light with 7 color choices

• Water Jetting
  Direction control on four back and two foot jets with variable speed and direction control on four side jets
• Higher pressure on the back/foot jets can be achieved by turning the flange on the variable speed side jets and lowering their output.
• In-Line Heater
  The water jetting includes an in-line water heater that will maintain and even slightly increase the water temperature during jetting. The heater engages automatically when the water jets are running.
• Air Jetting
  The air blower is fitted with variable speed control for total enjoyment. The twelve individual air injectors in the floor will bubble up around your legs, soothingly caressing your skin as they rise. Activating the air blower for about a minute before entering the tub can be a good idea for heating up the bubbles. While the air is warmed, it can still feel slightly cool when the bubbles first touch the skin. The sensation still feels fabulous. For additional hygiene, the air system has an automatic purge cycle that runs for 2 minutes - 20 minutes after being deactivated. This cleans and dries out the air lines.
• Chromotherapy
• For additional bathing relaxation, the system includes a seven color choice, mood enhancing chromotherapy underwater light.
• Ozone Sanitizing
  Ozone sanitizing is included with the hydro-spa jetting system. While the jetting tubes will drain very effectively, a little residual moisture retention is unavoidable. The ozone system, which only activates when the tub is jetting, will prevent bacteria build up. However, the regular maintenance suggested herein is a necessity for fully effective hygiene.
• Fittings Position
  The double shell tub design makes it possible to maintain the original bathtub appearance with no visible or remote jetting parts. All of the fittings are contained within the cavity in between the shells.
• Bath Salts and Bubble Bath
  It is safe to use bath salts and bubble bath. However, make sure the salts are dissolved before entering the bath or they can scratch the tub surface.
• Care and Maintenance
  Cleaning the high gloss acrylic finish requires a wipe down with a soft cloth and some very gentle liquid soap without abrasives.
• Recommended Periodic Maintenance
• To maintain excellent hygiene, we recommend the following preventative maintenance be carried out each 3-4 months.
• Fill you tub with lukewarm water to 2" above the top jet.
• Add one cup of household bleach.
• Activate all the jets in the fully open position.
• Allow the jets to run for 15 minutes.
• Switch the jets off and allow the water to sit for 15 minutes.
• Empty the tub and lightly rinse inside
